| Technical specification: | |
| Video line |
|
| Maximum protection | 4kV |
| Impulse discharge current | Up to 10kA |
| Stages of surge protection | 3 |
| Capacity protection circuit | Not more than 50pF |
| Fuse-off for Video line | 50mA |
| Power line |
|
| Fuse-off for power supply | 1A |
| Maximum protection | 4kV |
| Stages of surge protection | 3 |
| Maximum voltage | 14,4V DC |
| General | |
| Dimensions | 63 x 42,5 x 22,3 (mm) |
| Working temperature | -40~+60°C |
