TECHNICAL PARAMETERS OF THE RECEIVER

• type of receiving module: superreaction
• sensitivity: -100 dBm
• number of channels: 1
• memory capacity: 40 buttons
• nominal voltage supply: 12 V DC
• allowable voltage supply: 10-15 V DC
• static power consumption: 22 mA
• maximal power consumption: 104 mA
• capacity:
  relay output: 1A/ 30 V DC
• relay’s operating mode: mono, bi, temporary or 2key
• time scope for the mono mode: ~1s-4min15s
• operating temperature range: 0 to +40 °C
• dimensions (mm): 48*68*26

TECHNICAL PARAMETERS OF THE REMOTE CONTROL

• number of buttons: 4
• range (m): 100/ 200
• power: <5mW
• power supply: 1 battery 12V
• dimensions (mm) 29*61*11
