PTU-16R-PRO/InPoE – Protecție la descărcări electrice IP – 16 canale

16-channel LAN security panel with surge protection PROFFESIONAL series
Power distribution and protection of PoE for 4 cameras. Mount in RACK 19” (1U). 16 LAN channels. Wall-cailing bracket. Surge protection of 16 IP channels on PoE line (15,4W et. 48V). 2-level surge protection. Effectives up to 2~4kA for vain. Compatible with UTP 5 cat. Outdoor use prefer.
Types of Output/Input: version PTU: Krone / RJ45

Categorie:

Descriere

Specifications:

PARAMETER NAME VALUE
Data line
Number of channels 16
Degrees of protection 2 (gas tube, trancient bridge)
Capacity line–line 6-8pF @ 0V, 1Mhz
Capacity line-ground < 1pF
Protection level line–line 6V-1kV, 20V @ 100A , 8/20uS
Protection level line-ground 90V-4kV, 2~4kA, 8/20uS
Maximum voltage Uc 6,8V
Maximum power 8 / 20us (line-line) 2kW
Maximum voltage line-ground 90VDC
PoE line
Number of channels 16
Degrees of protection 2 (gas tube, transcient bridge)
Protection level line-line for PoE 10/1000uS 600W / 100A, 10/1000uS
Maximum voltage Uc for PoE 58V
Maximum current 200mA/channel
Protection level line-ground 90V-4kV, 2~4kA, 8/20uS Vc
Maximum line-ground voltage 90VDC
PoE work standard Complies with IEEE 802.3af of type B
Common features
Input connector (line) Krone
Output connector RJ-45
Output ground Yes
Fixing Rack 19″ 1U, wall
Additional options Replacable modules of different types, the protective cover
Dimensions 480 x 41 x 130 (mm)
Operating temperature -30~+60°C
