Descriere
The UC-82 offers the following: Remotely controllable relay outputs which follow JA-80 control panel programmable PG outputs Remote control of appliances using RC-8x controllers Relay output of JA-8x wireless detectors
Specifications
| Power supply: | 10 to 14V DC, standby consumption approx. 20mA |
|---|---|
| class=”techL”>X and Y relay contact rating: | max 2A/24V DC or 2A/120V AC |
| Low bat terminal: | max 100mA/24V DC |
| TMP terminals: | max 100mA/24V DC |
| Communication band: | 868 MHz, Oasis protocol |
| Minimum distance from transmitting devices | 1 meter |
| Operating environment class II | general, indoor -10 to +40 °C |
| Enclosure | IP40 EN 60529 |
| Mechanical immunity | IK08 EN 50102 |
| Dimensions: | 76 x 110 x 33 mm, antenna 35 mm |
| Can be operated according to ERC REC 70-03 | |
| This product complies with ETSI EN 300220, ETS 300683, and EN 60950 | |
