LST-4F LITE – Protecție la descărcări electrice Analogic – 4 canale (UTP Balun)

4-channel UTP balun with Ground Loop Video Separator
Wall mount / freestanding housing. 4 kanały Video. Ground loop video separator. Build in Video balun for each channel. Removable connector for twisted-pair. Free BNC connectors. Drain the load to the ground.

Categorie:

Descriere

Technical Specifications:
Impedance for coaxial cable 75 Ohm
Impedance for UTP twisted pair 100 Ohm
Max cable length 300m for color video signal, 500m for black-white video signal
Frequency range 20Hz ~ 10MHz
Segregation 600V (min.)
Insulation resistance 100M Ohms
Attenuation 0,4dB
Stages of surge protection PCB electrodes, gas tube, transient diode
Capacity protection circuit No more than 30pF
