Descriere
| Technical Specifications: | |
| Parameter | Value |
| Video Channels | 4 |
| Video output | BNC 75 Ohm, precision CNC |
| Impedance for coaxial cable | 75 Ohm |
| Impedance for UTP twisted pair | 110 Ohm |
| Frequency range | 0-10 MHz coaxial cable, 0-8Mhz UTP |
| Attenuation for coaxial cable | No more than 0.3 dB |
| Attenuation for UTP twisted pair | No more than 0.5 dB |
| Capacity protection circuit | No more than 50pF |
| Stages of surge protection | PCB electrodes, gas tube, transient diode |
| Discharge Current | 10kA gas tube, 57A transient |
| Discharge voltage | 75V gas tube, 8.2 V transient |
| Response time | 10us |
| Max protection | 4kV |
| Dimension | Standalone housing |
