| Technical Specification: | |
| Impedance UTP |
75 Ohm |
| Impedance BNC |
100 Ohm |
| Connector input (line) |
Socket srew |
| Connector output (device) |
Wire with male BNC |
| Frequency response |
42 MHz |
| Tłumienie | 0,2dB |
| Protect |
3 – Air ionizing, Gas tube, Fuse MOSFET |
| Protect line-ground |
Gas tube: 90V, 2x10kA @ 8/20uS |
| Protect line-line |
Transcient bridge: 6V, 100A @ 8/20uS |
| Maximum level overvoltage |
4kV |
| Capacity |
4pF |
| Range transmission AHD (max) | 720p: 320m 960p – 250m |
| Range transmission HD-CVI (max) | 720p: 450m 1080p – 250m |
| Range transmission HD-TVI (max) | 960p: 250m 1080p – 250m |
| Temperatura pracy | -40°C~+60°C |
