| Technical Specifications: | |
| Connection method | Male BNC connector + female BNC connector |
| Mode of operation | Passive – doesn’t require power |
| Effectiveness of elimination loop masses | High |
| Attenuation | Low (0~-3dB) |
| Frequency range | Wide (20Hz~10MHz) |
| Impedance of coaxial cable | 75Ohm |
| Impedance of twisted pair | 100Ohm |
| Effectiveness of insulation | 600VDC |
| Surge protection | 12Vrms |
| Built-in suppression filter |
Yes |
| Dimension | 72 x 28 x 22 (mm) |
